GL grade A L shape steel bar

GL grade A L shape steel bar is a kind of shipbuilding steel. GL grade A L shape steel bar with good toughness properties, higher strength and can be used in ship's hull structure. All of our stock is the high quality GL grade A L shape steel bar shipbuilding steel plate. GL grade A L shape steel bar has a large number of stocks.

GL grade A L shape steel bar specifications: 200 × 90 × 8 ×14, 200 × 90 × 9 × 14, 200 × 90 ×10 ×14, 250 × 90 × 9 × 14, 250 × 90 × 9 × 15, 250 × 90 × 10 × 15, 250 × 90 × 11× 16, 250 × 90 × 12 × 16, 300 × 90 × 10 × 16, 300 × 90 × 11× 16, 300 × 90 × 11 × 16, 300 × 90 × 12 × 17, 300 × 90 × 13 × 17, 350 × 100 × 11 × 17, 350 × 100 × 12 × 17, 400 × 100 × 11.5 × 16, 400 × 100 × 12 × 18, 400 × 100 × 13 × 18, 450 × 125 × 11.5 × 18

GL grade A L shape steel bar, GL-A chemical composition:

Grade

C max

Si max

Mn

P max

S max

Als min

GL-A

0.21

0.50

≥ 2.5C

0.035

0.035

-

CE: C+1/6Mn ≤ 0.40%
Cu ≤ 0.35%,Ni ≤ 0.30%

GL grade A L shape steel bar, GL-A Mechanical Property:

Grade

Rm

(MPa)

Re(MPa) min

A% min

Akv/J min

E.T °C

Thickness (mm)

≤ 50

>50-70

>70-100

L

C

L

C

L

C

GL-A

400-520

235

22

20

-

-

34

24

41

27

Related products: GL Grade B L shape steel bar,GL Grade A angle steel, GL Grade A bulb flat steel bar

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL grade A L shape steel bar, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL grade A L shape steel bar, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL grade A L shape steel bar, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact JW steel’s sales team. We will give you the GL grade A L shape steel bar, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL grade A L shape steel bar, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
